DJI Zenmuse H30

Unparalleled Vision, Day or Night

The all-weather, multi-sensor flagship Zenmuse H30 integrates four major modules—a wide-angle camera, a zoom camera, a laser range finder, and an NIR auxiliary light. Employing cutting-edge intelligent algorithms, it revolutionises perception and imaging standards, transcending the limitations of day and night vision. This makes it effortlessly suitable for a variety of operations, including public safety, energy inspection, water conservation, and forestry.

Zoom camera

  • Up to 34x optical zoom and 400x digital zoom
  • 40MP 1/1.8-inch CMOS sensor
  • Video resolution: max 3840x2160 @30fps

Wide-angle camera

  • Equivalent focal length: 24mm, DFOV: 82.1°
  • 48MP 1/1.3-inch CMOS sensor
  • Video resolution: max 3840×2160 @30fps

Laser range finder

  • Measurement range: 3-3000 m
  • Measurement accuracy:
    ≤ 500 m: ±(0.2 m+measurement distance×0.15%)‌> 500 m: ±1.0 m

NIR auxiliary light

  • Wavelength: 850 nm
  • FOV: 4.6±0.6° (round)
  • Safety ratingf: Class 1
  • Illumination range: Approx. 8m diametre circle at 100m distance

Further and clearer ‌vision

Up to 34× optical zoom‌ and 400× digital zoom

The Zenmuse H30 features a high-resolution 40MP zoom camera, supporting up to 34× optical zoom and an incredible 400× digital zoom. Compared to the previous generation, [2] it not only observes subjects at greater distances but also captures more details.

More stable imagery from the zoom camera

With DJI's latest image stabilisation algorithm, the Zenmuse H30 can effectively diminish shake in telephoto footage, delivering stable and clear imagery for detailed power line inspections.

Max 3000m laser range finder

The laser range finder boasts a measurement range up to 2.5 times greater than the previous generation, [3] accurately capturing the position information of subjects within a range from 3 m to 3000 m, [4] including linear distance from the camera, altitude, and GPS coordinates.

Enhanced night vision

Supports full-colour night vision

Both the zoom and wide-angle cameras of the Zenmuse H30 can switch to Night Scene mode in low-light conditions, enhancing live view and recording quality. This ensures operational efficiency and accuracy at night, enabling continuous operation from day to night.

Supports black and white night vision

In Night Scene mode, the Zenmuse H30's zoom camera supports IR Light for infrared enhancement and NIR illumination. [5] It switches the live feed to a grayscale image by removing the IR filter, thereby strengthening the contrast between light and dark areas, making it easier to locate subjects. When the NIR auxiliary light is enabled, the zoom camera can benefit from additional NIR illumination, which is especially helpful for covert night surveillance and search-and-rescue operations.

Smarter multi-scenario operations

Smart capture for improved imaging

In Smart Capture mode, the Zenmuse H30's zoom and wide-angle cameras automatically assess the brightness of ambient light and the dynamic range, and apply intelligent image algorithms. This ensures the output of photos with natural transitions between light and dark and rich details, even in environments with high dynamics, strong light, or low light.

Electronic dehazing

In conditions such as smog or high atmospheric humidity, the Zenmuse H30's zoom camera employs a new Electronic Dehazing function [11] to enhance image clarity. It offers low and high dehazing levels to suit different operational environments and requirements.

Superior environmental adaptability

IP54 ingress protection

With an IP54 dust and water resistance rating, [12] the Zenmuse H30 can operate safely and reliably even in harsh working conditions.

-20°C to 50°C operating temperature

The Zenmuse H30 is built to work in temperatures ranging from -20°C to 50°C, meeting all-weather operational needs.

More reliable information sync and retention

Supports pre-recording

All cameras of the Zenmuse H30, including the zoom, wide-angle, and infrared thermal cameras, support pre-recording. They can retain footage from 10, 15, or 30 seconds before the formal recording starts, ensuring a more complete record and capturing key information that may otherwise be quickly lost.

Media and transmission encryption

The Security Code function allows for the encryption of microSD cards, fully protecting your files. AES-256 encryption technology ensures the security of data transmission between the remote controller and the aircraft. Additionally, it supports one-click log clearance to prevent information leaks.

Cloud information sync

Operators can check live views from the Zenmuse H30 through the cloud platform on DJI FlightHub 2 to stay up to date with on-site dynamics. This enables rapid remote command and facilitates coordinated air-to-ground operations.
